Thinking locally

Today’s computer chips are not optimized for sparse data—in fact, the reverse is true. Because fetching data from the chip’s main memory bank is slow, every core, or processor, in a modern chip has its own “cache,” a relatively small, local, high-speed memory bank. Rather than fetching a single data item at a time from main memory, a core will fetch an entire block of data. And that block is selected according to the principle of locality.

It’s easy to see how the principle of locality works with, say, image processing. If the purpose of a program is to apply a visual filter to an image, and it works on one block of the image at a time, then when a core requests a block, it should receive all the adjacent blocks its cache can hold, so that it can grind away on block after block without fetching any more data.

But that approach doesn’t work if the algorithm is interested in only 20 books out of the 2 million in an online retailer’s database. If it requests the data associated with one book, it’s likely that the data associated with the 100 adjacent books will be irrelevant.

Going to main memory for a single data item at a time is woefully inefficient. “It’s as if, every time you want a spoonful of cereal, you open the fridge, open the milk carton, pour a spoonful of milk, close the carton, and put it back in the fridge,” says Vladimir Kiriansky, a PhD student in electrical engineering and computer science and first author on the new paper. He’s joined by Amarasinghe and Yunming Zhang, also a PhD student in electrical engineering and computer science.

Batch processing

Milk simply adds a few commands to OpenMP, an extension of languages such as C and Fortran that makes it easier to write code for multicore processors. With Milk, a programmer inserts a couple additional lines of code around any instruction that iterates through a large data collection looking for a comparatively small number of items. Milk’s compiler—the program that converts high-level code into low-level instructions—then figures out how to manage memory accordingly.

With a Milk program, when a core discovers that it needs a piece of data, it doesn’t request it—and a cacheful of adjacent data—from main memory. Instead, it adds the data item’s address to a list of locally stored addresses. When the list is long enough, all the chip’s cores pool their lists, group together those addresses that are near each other, and redistribute them to the cores. That way, each core requests only data items that it knows it needs and that can be retrieved efficiently.

That’s the high-level description, but the details get more complicated. In fact, most modern computer chips have several different levels of caches, each one larger but also slightly less efficient than the last. The Milk compiler has to keep track of not only a list of memory addresses but also the data stored at those addresses, and it regularly shuffles both around between cache levels. It also has to decide which addresses should be retained because they might be accessed again, and which to discard. Improving the algorithm that choreographs this intricate data ballet is where the researchers see hope for further performance gains.

“Many important applications today are data-intensive, but unfortunately, the growing gap in performance between memory and CPU means they do not fully utilize current hardware,” says Matei Zaharia, an assistant professor of computer science at Stanford University. “Milk helps to address this gap by optimizing memory access in common programming constructs. The work combines detailed knowledge about the design of memory controllers with knowledge about compilers to implement good optimizations for current hardware.”
